More Double Ruffles: Philly 87.35.827

2nd draft; pics rev.

This beauty is at the Philadelphia History Museum, dated 1750-1800, #87.35.827.  It is crafted of very fine linen, 11 1/2″ from tip to CF.  A simple lappet, with those kissing strings and another example of a double ruffle. There is no public catalog record for this cap.

The Original

18th C linen cap from the Philadelphia History Museum.
Philly #87.35.827 is a linen lappet with doubled ruffles.

The Caul is about 8″ tall by 4 1/4″ wide (measured flat). A 3/8″ casing at the bottom encloses a very thin linen tape. These tapes are attached to the far side of the channel, come out on the inside under the ear, and then hang down 19″ on one side and 12″ on the other. I assume the short tape is torn. The front edge hem is 1/16″, and when it turns into a whipped gather over the top, there are 26 miniature pearl-like stitches per inch.  I counted.

The headpiece is also hemmed with that tiny hem all around, and butted to the caul and ruffle.

That hem makes an anchor onto which we can whip the ruffle.  The ruffle is doubled. It’s made by hemming one rectangular piece of cloth all the way around, folding it off center, and whipping it to the headpiece on the fold.  Note that for that to work, the outside edges have to be hemmed to opposite sides of the rectangular cloth.  As is usual, the ruffle is only gathered enough to get around the point, and stops at the join with the caul. The ruffle gets skinnier as it rounds the tip, and skinnier still as it goes up the back of the lappet. (1 1/4″ at CF, but 3/4 at the far ends.)  It is pieced.

The ends of the lappets are reinforced to hold the 1/2″ linen tabby weave tape. It is 4″ long, just enough to make a bow.

Tip of the lappet showing string attached.
I only have one other good photo: a close up of the gathered turn of the lappet.













Questions that remain

This is from the Philadelphia History Museum, and most of its clothing collection is Quaker, and this cap is noted as Quaker.  In the 18th C, that did not mean fossilized fashion.  You could be a “gay Quaker” or a “plain Quaker”, which meant you went in for fashionable colors and embellishments, or you chose muted and simple clothing. Don’t take that to mean not fashionable, or not expensive. If you could, you wore silk of course.  It’s on my list to write about Quaker fashion, as it was one of the many rabbit holes I went down on this journey.

Portraits

Mrs. James Smith, painted by Charles Wilson Peale, 1776, wears a cap like this one.  The gathers under her chin are very subtle. The ties that hold the lappets are visible.  She has added a ribbon.  This is another example of an older woman in a lappet. I like it that her chins are still visible!  She looks friendly. I bet this grandchild was a great favorite.

https://americanart.si.edu/artwork/mrs-james-smith-and-grandson-19292
Mrs. Smith wears a double-ruffle on her cap.



The Reproduction

Saines' repro of double ruffle cap on green background, with snow.
It’s frigid and snowing today. My repro of Philly 87.35.827.
Saines' repro on drawing from notes shows discrepancies.
After it was all made, I laid it on the drawing I made and realized it is about 1″ too small all over. *sigh* Philly 87.35.827 repro.

This was the cap that finally showed me how the double ruffles were put together.  It was not nearly as clear in the first one of these I saw. Whipping the folded edge was neat and easy.

But, I didn’t finish opposite sides of the ruffle, so the inside ruffle shows its hem. But it’s really teeny — you’d never notice.  And anyway, you can see both sides of the ruffle’s edge when you wear it.

I always wonder how they would know where to put the gather on the ruffle.  Did they sew down from the CF, and do the gather as they went, where it needed to sit?  I don’t have any evidence that there were patterns with that level of detail to follow. So this time I tried it that way, whipping it to the headpiece, and gathering as I went.  That’s a whole new level of skill!  I got it too tight again. Because you are sewing along a folded piece, at least you don’t have to roll that edge before you join it.

Which brings me back to the ruffle getting skinnier as it goes.  I actually cut this out with a built-in taper.  I’d like to go back to the original and see if I could find a taper in the ruffle.  It has to, doesn’t it?  and if the ruffle’s edges deviate from the straight grain, are shaped to taper on purpose, it means the place where the gather goes is predetermined. That was hard to explain.  Do you see what I mean? Who did that math?

Another complicating factor is how much to allow for the gathered part. I was taught that for ruffles you allow about a 2:1 ratio. That is, allow twice as much cloth for the space you want to cover with ruffles.  12″ yoke? 24″ of cloth. But I am learning that the required measure depends on several variables. Most important is the weight of the cloth.  No one can make 26 whipped gathers to the inch with a 6 oz. linen.  But with super fine, maybe 2.5 oz., you almost can.  So lighter cloth takes up more in a gather than heavy cloth. It also depends on how small a gather you can produce (stroke or whipped). It helps to have a long, fine needle, like a milliner’s needle, and fine, strong thread. Silk is a good choice. The needle should not leave a visible hole in the cloth, and the thread should be the same or lighter weight than the threads of the cloth.

My Notes

Click here for notes: philly 87.35.827

I didn’t include my pattern because it was so off measure. I need to redo this one.

Thank Yous and Permissions

Kristen Froehlich, Director of the Collection and Exhibits at the Philadelphia history Museum at the Atwater Kent gave me permission to use images I made and discuss this artifact here.

Photos by the author.

Other Related Scholarship

There is no other research about this cap as far as I know.















Love Those Double Ruffles: Smiths 6608-C

2nd draft; pics rev.

Several caps I’ve seen have double ruffles.  On Smiths 6608-D, they are made of finer cloth than the rest of the cap, and the finishing hem, about 1/16″ across, has stitches so fine I couldn’t see them to count them.  The effect is like an edge of tiny silk ribbon.

Lappet cap shown on graph paper for size.
Smithsonian 6608-D has a doubled ruffle whose edge is invisibly hemmed.

The cap is housed in the textiles collection of the Smithonian’s National Museum of American History*, a part of the Copp Collection. The museum date is 1775-1799. The record for this item is not online.











The Original

The caul and headpiece are made from handkerchief-weight linen, but the ruffles are finer.  The headpiece, including the lappets, is 10 1/2″ from tip to top.  The Caul is stroke-gathered to the headpiece, and the edge left unfinished inside.  A casing 1/4″ wide along the nape is made of a piece sewn in (I’m not for sure about that, but I can see the edges in the photos) to create the channel for Kissing strings, 18″ long, of 1/8″ linen tape.  The tapes come out on the outside, just where the caul, headpiece, and ruffle all come together.

The headpiece is pieced at the top, felled together.  It is hemmed all around with a tiny hem and then butted to the caul. You can see the stitches, like whip stitches, joining the two, but loose enough that the 2 hems sit side by side.

Then the ruffles:  hemmed on the front side, and whipped to the headpiece, with a gather only around the lappet tip.  The top ruffle is about 1/4″ skinnier than the bottom ruffle.  I decided later, when I’d seen a couple more of these, that the ruffle was made from one piece of cloth, folded, and joined through the gutter.

The ruffles don’t go all the way around the back, but end 2 1/2″ past the point where the strings come out.  Right here, the straight grain of the cloth has to bunch to get around the curve, so although it isn’t actually gathered, it appears so.  But the top ruffle ends earlier, about an inch past the tip of the lappet….

Which makes me wonder. You can see in this picture, which shows the ruffle laid open on the left side, that there’s a little bit of cloth puckered up under there.  Last detail: the ruffle goes from 1 1/4″ wide at the CF to 3/4″ wide at the other end, so maybe the difference is hidden here?  After this point, there’s a felled join, and the single ruffle finishes the round.

Look closely to see a (folded) piece of cloth between the layers of the ruffle.
What is the little fluff hiding between the layers of the ruffles?





Closeup of CF of cap, inside.
The stroke gathers visible inside. And the exact and fine hems and joins.
Close up of bottom of caul showing tape coming out at join.
The long tapes come out at the point where the caul, headpiece, and ruffle intersect. You can also see what looks like a pieced channel for the gather.
Close up of ruffles at the tip of the lappet.
The skinnier ruffle (1″ at its widest) lays on top of the wider ruffle (1 1/4″ at its widest). The folded cloth, once hemmed, would be 2 1/4″ wide, folded at 1″, and whipped on at the fold. … I think.

Questions that remain

Why do ruffles get skinnier on the sides and back than in the front?  It’s confusing because the grain of the cloth is straight on the outer edge, but the inner edge gets progressively more eaten up by the rolling of the whipped join?  On purpose?  Why?

And the Kissing Strings again.

Portraits

Remember Mrs Galloway?  Her cap is an exact match.

18th c portrait of woman in plain brown gown with lappet cap.
Mrs. Richard Galloway, by John Hesselius (1728–1778), 1764. Held at the Metropolitan Museum of Art



The Reproduction

No repro yet.

My Notes

Click here for notes: smiths 6608 c notes

Thank Yous and Permissions

Nancy Davis, Curator of Textiles at the Smithsonian’s National Museum of American History, helped me to identify items in that collection that were useful to this study. That was no small feat, as records were spread across several legacy cataloging systems, and details were minimal.  I can only hope I found what there was to find!

Photos by the author.

Other Related Scholarship

I am not aware of any other scholarship about this cap.

*. . . which is not the same thing as the Smithsonian’s Cooper Hewitt, in NYC. Their textiles section was under construction at the time of this study, so I didn’t get to see their artifacts.
